High Voltage Current Transformer

JDZ(F)W-35W2 voltage transformer

Item No.: JDZ(F)W-35W2
Apply to outdoor substation in rural areas can also be used for industrial,enterprise small change,power distribution.
Description
Description
Introduce

This is type of voltage transformer for outdoor epoxy resin(Switzerland,Ciba CW5837)casting a fully enclosed structure.

Applies to AC 50Hz ,Rated voltage of 10kV and below  the power system for voltage and power measurment and relay protection .

Apply to outdoor substation in rural areas can also be used for industrial,enterprise small change,power distribution.

Features
The voltage transformer of this type,the pillar structure ,fully enclosed ,small size ,quailty ,suitable for any location,installed in any direction.
Safe and reliable ,there are four mounting holes on the channel.
The second outlet side of the terminal protection cover,below the outlet hole,and anti-theft measures.
Technical Parameter



TRANSDUCER
Load power factor 0.8(lag)
Pollution Class Class II
Product standard GB1207



Specification



Type Rated voltage ratio Accuracy class  Rated secondary load limit output Reted insulating level
JDZW-35W2 35/0.1 0.2,0.5 30,80 1000 40.5/95/200
JDZFW-35W2 35/0.1/0.1 0.2/0.2 , 0.2/0.5 , 0.5/0.5 30/30 , 30/50 , 50/50 800

Dimensions



JDZ(F)W-35W2



Accuracy test

24Hs online service
365Ds NON-Stop Production 20Ys Professional Manufacturers
Professional designer and manufacturer of current transformer,
cooperated with Siemens ,schneider Fuji electrical softbank LG samdsung.
Tel:13968747975
Add:(Zhejiang Lierde Relay Co., Ltd.) Xinguang Ind. Zone, Liushi Town, Wenzhou, Zhejiang, China
